Paper Cup Lid Ua Tshuab
Pkabpiav qhia:
Paper Cup Lid Ua Tshuab
TECHNICAL DATA
|
Qauv |
GD-PL100 |
|
Moulding dimension |
Qhov siab: 8-15 hli; Txoj kab uas hla: 55-100 mm |
|
Cov khoom siv raw |
Ib los yog ob npaug PE / PLA coated ntawv, pbs coated ntawv (250-350g/m2) |
|
Ceev |
60-80 pcs/min |
|
Hwj chim |
380V 50Hz 3Phase lossis Customize 10kw |
|
Ua Haujlwm Cua Qhov Chaw |
{{0}}.4Mpa, Huab cua tawm: 0.3cbm/min |
|
Qhov hnyav |
2200 Kg |
|
Dimension |
2500*1300*1650(L*W*H) |
PRODUCTS FEATURE:
Lub khob kas fes lub hau uas tsim los ntawm GD-PL100 daim ntawv khob lub hau ua tshuab haum nruj rau lub qhov ncauj ntawm lub khob kas fes, uas tuaj yeem ua kom qis qis ntawm kas fes kub mus rau qee qhov, tswj kom sov thiab saj ntawm kas fes, thiab txo qis. poob ntawm tsw. Nws tseem tuaj yeem tiv thaiv kas fes kom tsis txhob nchuav thaum nqa lossis txav mus los, ua kom cov txheej txheem haus dej huv thiab huv.
Hluav taws xob configurations
|
Khoom npe |
Hom |
|
Inverter |
Schneider |
|
PLC |
Delta |
|
Kov npo |
Flexem |
|
Servo tsav |
Delta |
|
Hloov |
Chnt |
|
Cua kub system |
Leister cua sov ntsiab |
|
Khoom relay |
Fotek |
|
Encoder |
Omron |
|
Mini relay |
Schneider |
|
Khawm |
Cov ntaub ntawv |
|
Servo lub cev muaj zog |
Delta |
1. Cov khoom yog pub rau hauv daim ntawv yob, thiab lub teeb lub qhov muag daim ntawv khob lub hau ua tshuab tuaj yeem ua tiav 0 pov tseg ntawm kev pub mis.
2. Lub khob hau ua tshuab siv Swiss imported Leister hom cua sov ntsiab lus, ceramic kub cua preheating molding nyhuv yog zoo dua thiab ruaj khov.
Peb qhov kev pabcuam:
● Peb muaj 1,000 square meter warehouse khaws cov tshuab thiab lwm yam khoom siv.
● Cov chaw ua haujlwm txawv teb chaws thiab cov neeg sawv cev hauv qee lub tebchaws.
● Kev tshawb fawb ywj pheej thiab kev tsim kho tshuab, txhawb OEM / ODM kev pabcuam.
● Engineer dispatch kev pab cuam, kev txhawb nqa ntawm qhov chaw Hoobkas kev teeb tsa thiab kev cob qhia.
Vim li cas ho xaiv peb?
● Peb muaj tag nrho cov khoom siv raw khoom nrog cov khoom zoo heev los pab cov neeg siv khoom pib ua haujlwm zoo.
● Muab ib qho kev daws teeb meem rau daim ntawv khob cov kab ntau lawm, siab nruab nrab thiab automated.
● Lub chaw tsim khoom npog thaj tsam ntawm 30, 000 ㎡.
Automatic tuag txiav tshuabNtimStyle:
Nyob rau hauv rooj plaub ntoo los yog ntoo pallets raws li
FAQ
Q: Puas yog koj cov khoom hauv Tshuag lossis customized?
Q: Lub sijhawm ua haujlwm ntawm koj lub tshuab ntev npaum li cas?
Q: Yuav ua li cas rau nruab lub tshuab tom qab kev yuav khoom?
